Machines Arriving
Soon or Just arrived





Ikegai 20" x 60" centre lathe
(Very high quality Japanese machine)
(Now In)



Elliot Vertical Milling
& Boring Machine
(Now In)


Boxford CUD Lathe
(Now In)



Powered Hydraulic Press
25 TON
(Now In)

Colchester Student MK1
Roundhead Lathe
(Now In, & another one in prep.)

Ajax Heavy Duty Turret
Milling Machine
(Now In)

Acra Turret Milling Machine
with Anilam 3000  3 Axis CNC control
(CNC and Manual Operation)
(Now In)



===============================


Machines & Accessories
Now In



Colchester Student Roundhead
Centre Lathe



Sweet runner, very quiet, with tooling, tooling as seen in photo,
6" centre height x 24" between centres, imperial & metric screwcutting
gearbox, powerfeeds to carriage & crosslide
3 morse taper to the tailstock, 4 way toolpost, rear splash guard,
gap bed, dual speed 3 phase motor so this lathe has 16 speeds,
(coolant pipework but no pump fitted) with machine manual.
Older machine not a lot of money and will still do the job

£850.00....(No v.a.t. to add)

Any questions, ring on Steve on
01623-491001 or 07710-401194

You are welcome to see the lathe running, (recommended)
ring to arrange this.

You can collect the lathe yourself and I can load free of charge
with our forklift.

Crane lorry delivery available, we use a regular driver and you can have
his phone number to make the arrangements.

I prefer payment by Cash, debit cards, or bank transfer.....







=========================================================

Colchester Student Roundhead
Centre Lathe





(Another Student roundhead, same colour as above)
(undergoing preparation)

Photo's Soon





=========================================================

Ikegai 20" x 60" Centre Lathe
(Very high quality Japanese machine)
(large capacity....20 inch swing over the bed)




 (Undergoing preparation)



Photo's and description soon
or ring 07710-401194







=========================================================

Boxford CUD Centre
Lathe

Nice machine, quiet runner

4.5" centre Height x 18" between centres,ten spindle
speeds 40 to 1400 rpm on a 240 volt single phase motor,
powerfeeds and screwcutting to carriage,
screwcutting by changewheels,
Santon forward and reverse switch to start,
4" 3 jaw Burnerd chuck with inside & outside jaws,
Dixon S1 quick-change toolpost with 2 toolholders,
with some other tooling drills/sleeve etc

£625.00....(No v.a.t. to add)

Any questions, ring on Steve on
01623-491001 or 07710-401194

You are welcome to see the lathe running, (recommended)
ring to arrange this.

You can collect the lathe yourself and I can load free of charge
with our forklift.

will fit in a small trailer or van

Crane lorry delivery available, we use a regular driver and you can have
his phone number to make the arrangements.

I prefer payment by Cash, debit cards, or bank transfer.....







=========================================================

Elliott Vertical
Milling & Boring Machine

Elliott  milling, positional drilling and boring machine

16" x 7" tee slot table, rise and fall head, hand fine feed to quill,
power downfeed to quill, 2 h.p. 240 volt single phase motor,
10 speeds 180 to 4000 rpm, spindle collets, ER25 collet chuck
and 5 collets, boring head, drill chuck, overall dimensions are;
 22" wide x 32" deep x 72" high, weight is about 500kg (a guess)

£1250.00....(No v.a.t. to add)

Any questions, ring on Steve on
01623-491001 or 07710-401194

You are welcome to see the mill running, (recommended)
ring to arrange this.

You can collect the mill yourself and I can load free of charge
with our forklift.

Crane lorry delivery available, we use a regular driver and you can have
his phone number to make the arrangements.

I prefer payment by Cash, debit cards, or bank transfer.....

Ring me on the numbers above with questions or to pay for the machine.







=========================================================

25 Ton Power Press

Enerpac 25 ton ram, rise and fall table, 20" between the
frame, 3 phase 3 h.p. hydraulic powerpack, with safety
perspex screen and contactor box, about 14 or 15 " stroke.
overall dimensions;  35" wide x 35" deep x 74" high

£395.00....(No v.a.t. to add)

Any questions, ring on Steve on
01623-491001 or 07710-401194

You are welcome to see the press running, (recommended)
ring to arrange this.

You can collect the press yourself and I can load free of charge
with our forklift.

Crane lorry delivery available, we use a regular driver and you can have
his phone number to make the arrangements.

I prefer payment by Cash, debit cards, or bank transfer.....

Ring me on the numbers above with questions or to pay for the machine.





=========================================================

Wicksteed 6" Power
Hacksaw

6" capacity (actually measures 7" under the frame)
in round bar or box section, swivelling vice
for mitre cutting hydraulic downfeed control 3 phase motor

£250.00.....(No v.a.t. to add)

Any questions, ring on Steve on
01623-491001 or 07710-401194

Easy delivery by various methods to suit you
I prefer payment by Cash, debit cards, or bank transfer.....

will fit in a small van or trailer,

Low cost trailer delivery possible, ring to discuss this

Ring me on the numbers above with questions
or to pay for the machine






========================================================

Bridgeport Varyspeed
Series 1 Turret
Milling Machine

Bridgeport turret milling machine
Nice machine, digital readout, powerfeed with rapids to table,
Variable speeds up to 3750 rpm, power feed to head,
tilt and swivel head, Dual dials, R8 taper to quill, machine light,
coolant system, splash tray, machine manual with parts list.

£2450.00....(NOW SOLD)

Any questions, ring on Steve on
01623-491001 or 07710-401194

You are welcome to see the mill running, ring to arrange this.

You can collect the mill yourself and I can load free of charge
with our forklift.

Crane lorry delivery available, we use a regular driver and you can have
his phone number to make the arrangements.

I prefer payment by Cash, debit cards, or bank transfer.....

Ring me on the numbers above with questions or to pay for the machine.


=========================================================
Picture Frame Guilotine


Unknown make, good solid cast iron construction
the wood guides are fully adjustable,
the blades are frighteningly sharp, mounted on a stand
but could be mounted on a bench.

£150.00....(No v.a.t. to add)

Any questions, ring on Steve on
01623-491001 or 07710-401194

You are welcome to view, ring to arrange this.

You can collect the Guilotine yourself and I can assist with the loading,
it will dismantle to transport

I prefer payment by Cash, debit cards, or bank transfer.....

Ring me on the numbers above with questions or to pay for the machine.









=========================================================
Ajax AJT Heavy Duty
Turret Mill







(More details and photo's soon)





Ajax H/D AJT Milling Machine
Tilt swivel head, power down feed to head, powerfeed gearbox
to table, 16 spindle speeds, 54" x 10" tee slot table, 40 international
spindle taper, with tooling splash tray and instruction manual

£1850.00.....(No v.a.t. to add)



You are welcome to see this mill running, ring to arrange this.

You can collect the mill yourself and I can load free of charge
with our forklift.

Crane lorry delivery available, we use a regular driver and you can have
his phone number to make the arrangements and costings.

I prefer payment by Cash, debit cards, or bank transfer....









=========================================================
Brierley ZB32
Drill Point Grinder


Brierley ZB32 on the makers cabinet, ex-rolls royce,
sharpens drills up to 32mm (1.250 inches)
6 jaw chuck with instruction manual, 3 phase motor,
with spare wheels and some other tooling

£875.00.....(No v.a.t. to add)

You are welcome to see this grinder running, ring to arrange this.

You can collect it yourself and I can load free of charge
with our forklift. it will fit in a van ok

I prefer payment by Cash, debit cards, or bank transfer....







=========================================================
Colchester Student MK2
Centre Lathe

6" centre height with 24" between centres, 16 spindle speeds
34 to 1500 rpm from a dual speed 400/440volt 3 phase 3 h.p. motor,
Imperial & metric screwcutting gearbox with powerfeeds to the carriage
and crosslide, 3 morse taper to the tailstock, gap-bed, imperial dials,
3 jaw and 4 jaw chucks, faceplate and some other tooling, 4 way
toolpost, coolant system, rear splash guard, machine lo-vo light
with instruction manual/parts list.

£1250.00.....(No v.a.t. to add)


You are welcome to see this lathe running, ring to arrange this.

You can collect the lathe yourself and I can load free of charge
with our forklift.

Crane lorry delivery available, we use a regular driver and you can have
his phone number to make the arrangements.

I prefer payment by Cash, debit cards, or bank transfer.






=========================================================
Colchester Student MK2
Centre Lathe



6" centre height with 24" between centres, 16 spindle speeds
34 to 1500 rpm from a dual speed 400/440volt 3 phase 3 h.p. motor,
Fitted with genuine Colchester 'Matrix' clutch, (motor runs all of the time)
genuine Dixon Quick-change toolpost with 2 toolholders
Imperial & metric screwcutting gearbox with powerfeeds to the carriage
and crosslide, 3 morse taper to the tailstock, gap-bed, imperial dials,
3 jaw and 4 jaw chucks, and some other tooling, 4 way
toolpost, coolant system, rear splash guard, machine light
with instruction manual/parts list.

£1250.00.....(No v.a.t. to add)


You are welcome to see this lathe running, ring to arrange this.

You can collect the lathe yourself and I can load free of charge
with our forklift.

Crane lorry delivery available, we use a regular driver and you can have
his phone number to make the arrangements.

I prefer payment by Cash, debit cards, or bank transfer....






=========================================================
Harrison M500 Gap-Bed
Centre Lathe

Harrison M500
500mm  swing over the bed with 1500 mm between centres,
Anilam wizard 2 ais digital readout system
induction hardened bed with detachable gap piece, 730mm swing in gap,
18 spindle speeds 31 to 1600 rpm,  9.5 kW (12.5 hp) 3-phase,
forward and reverse,  electromagnetic spindle brake manufactured by Warner.
No. 8 D-1 Camlock nose, the 83 mm bore spindle carries a reduction sleeve to
sleeve to hold a 5 Morse-taper centre, English/metric screwcutting gearbox,
The tailstock is fitted with a 73 mm diameter (2.875") spindle
with 155 mm (6.125") of travel and a No. 5 Morse taper, screwcutting dial,
Ainjest quick threading attachment,
12" 3 jaw chuck with inside and outside jaws,
Dixon Quick Change Toolpost, coolant supply
The weight is 2040kg

Overall length is 2750 width is 1050mm

£3750.00....(No v.a.t. to add)

Any questions, ring on Steve on
01623-491001 or 07710-401194

You can see the lathe running, ring to arrange this.

You can collect the lathe yourself and I can load free of charge
with our forklift.

Crane lorry delivery available, we use a regular driver and you can have
his phone number to make the arrangements.

I prefer payment by Cash, debit cards, or bank transfer.....

Ring me on the numbers above with questions or to pay for the machine.

=========================================================
Boxford Centre Lathe
Long-Bed Ex-College Training Lathe

140 mm (5.72") centre height "TR” Model Industrial Training Lathe.
750 mm (30") between centres,
 heavy and rigid bed (induction hardened
and ground as standard) cut away under the spindle for a length of 150 mm (6")
to give a slightly increased swing. Robust cabinet stand with a lockable
storage cupboard and full-length splash back that incorporated a tool tray.
35 mm (1.375") bore and a hardened D1-3" nose, 3 Morse taper to the tailstock,
Powered by a 1.5 kW (2 h.p.) 3 phase dual voltage motor fastened to an
adjustable plate behind and below the headstock, (Conversion to 240volt
(Conversion to 240volt single phase would not be difficult… or use and inverter)
a useful 54 to 3000 r.p.m range of spindle speeds.
has a screwcutting gearbox with powerfeeds to the carriage and crosslide

on the makers stand, with rear splash guard and instruction manual

with new chuck

£1950.00....(Under Offer)

Any questions, ring on Steve on
01623-491001 or 07710-401194

You can see the lathe running, ring to arrange this.

You can collect the lathe yourself and I can load free of charge
with our forklift.

Crane lorry delivery available, we use a regular driver and you can have
his phone number to make the arrangements.

I prefer payment by Cash, debit cards, or bank transfer.....

Ring me on the numbers above with questions or to pay for the machine.




=========================================================
Herbert Single Spindle
Drilling Machine



 Herbert single spindle drilling machine,
rise and fall head, rise and fall tee slot table,
18" x 18" table, Pull down quill, 13" x 15" tee slot area,
8 quick-change spindle speeds, 2 morse taper to quill,
4 speed 3 phase motor with quick reverse,
with a range of drills and sleeves

£375.00....(No v.a.t. to add)

Any questions, ring on Steve on
01623-491001 or 07710-401194

You can see the drill running, ring to arrange this.

You can collect the drill yourself and I can load free of charge
with our forklift.

Crane lorry delivery available, we use a regular driver and you can have
his phone number for a price or to make the delivery arrangements.

I prefer payment by Cash, debit cards, or bank transfer.....

Ring me on the numbers above with questions or to pay for the machine.









=========================================================
Kerry Centre Lathe




Recently removed from a modelmakers workshop,
5.5" centre height (11" swing) and about 24" between centres,
Straight Bed, 9 spindle speeds from 39 rpm up to 1500 rpm,
spindle hole I am guessing about 30mm, 3 morse taper to the tailstock,
screwcutting gearbox with powerfeeds
to the carriage and crosslide,
imperial dials, 4 way toolpost, very well tooled with a 3 jaw chuck,
4 jaw chuck, fixed and travelling steadies and some other tooling as seen
in the photo's,   3/4 h.p 1420 rpm 240 volt single phase motor,
There is also a quite nice 'homemade' vertical milling attachment
which was made by the previous owner which also has a single phase motor,
the lathe is fitted with a proper clutch and it also has a
 machine light.
The overall dimensions are; 57" long x 24" deep x 48" high
5.5"
 centre height (11" swing) and about 24" between centres,
.....

£750.00....(Now Sold)

Any questions, ring on Steve on
01623-491001 or 07710-401194

You can see the lathe running, ring to arrange this.

You can collect the lathe yourself and I can load free of charge
with our forklift.

Crane lorry delivery available, we use a regular driver and you can have
his phone number for a price or to make the delivery arrangements.

I prefer payment by Cash, debit cards, or bank transfer.....

Ring me on the numbers above with questions or to pay for the machine.



=========================================================
Morgan Guilotine
(Seen working on site)

6 mm cut in in mild steel x 1500 mm, footswitch control,
support arms, back gauge, can be seen working
as it is still in use on site,
viewing at NG21 0TA

£1600.00.....(SOLD)

Loading is available on site





=========================================================

INVERTERS
Operate 3 phase machinery from a normal
240 volt single phase supply

The easy answer to using 3 phase machinery
in the single phase workshop

240 volt single phase input, 240 volt and 415 volt
3 phase output,
suitable for all machinery with 3 phase motors.


Dual voltage motors are motors that can be changed over
simply in the terminal box to operate on either
240 volt 3 phase or 415 volt 3 phase
(It will state this clearly on the motor plate)

Inverters for dual voltage motors are cheaper to buy

Inverters with 415 volt output will cost more

Ring me to discuss this if you are confused


Most modern motors are suitable

These inverters allow full direct control of the motor
and all of its operating characteristics...........
start up,  build up of speed,  variation of speed,
motor overload protection and braking.


If you have an 8 speed gearbox you will have
variable speeds in between each gear
or right through the range


No need to rewire the machines electrics to suit
as you can connect direct to the motor terminals

Available sizes (rating)

0.37 kw (1/2 h.p.)
0.55 kw (3/4 h.p.)
0.75 kw (1.0 h.p.)
1.1 kw (1.5 h.p.)
1.5 kw (2 h.p.)
 2.2 kw (3 h.p.)
 3.0 kw (4 h.p.)
   4.0 kw (5.5 h.p.)

Prices start from £85.00...(no v.a.t. to add)

Motors suitable for use with these Inverters
are also available new, email if you need one







==========================================================




The Machines Below Were
Sold Recently
Left on the site to give you an idea
of our pricing policy



Harrison M400
Centre Lathe

 Harrison M400
400mm  swing over the bed with 1000 mm between centres,
induction hardened bed, 18 spindle speeds 40 to 2000 rpm,
  3-phase motor with forward & Reverse, D1-8 Camlock nose,
  electromagnetic spindle brake manufactured by Warner.
 65 mm bore spindle carries a reduction sleeve to
 hold a 5 Morse-taper centre, Imperial/metric screwcutting gearbox,
The tailstock is fitted with a 73 mm diameter (2.875") spindle
with 155 mm (6.125") of travel and a No. 5 Morse taper, screwcutting dial,
10" 3 jaw chuck with inside and outside jaws, Taper turning attachment,
4 way Toolpost, coolant supply
The weight is 1740kg


£1950.00....(SOLD)





=========================================================

Herbert Surface Grinder

Small hand operated surface grinder, about 6 inch wheels
2800 rpm 3 phase dual voltage motor,
with a 10" x 5" magnetic chuck
weighs about 300kg

£475.00.....(SOLD)

Any questions, ring on Steve on
01623-491001 or 07710-401194







=========================================================

Smart & Brown Model 'A'
Centre Lathe

MK2 Model

Toolroom standard machines,  these Smart and Brown lathes are
the best money can buy, in very nice condition showing very little
wear and very quiet when running,  9" swing with 18" between centres,
2 morse taper to the tailstock, Norton style screwcutting gearbox
with powerfeeds to the carriage and crosslide, 12 spindle speeds
40 to 1800 rpm, imperial dials, 3 phase motor, taper turning attachment
(sliding shoe missing but easy to make)   quick change toolpost,
forward and reverse switch, 3 and 4 jaw chucks, driver plate.
and an instruction manual
The overall dimensions are 55" long x  27" deep x  47" high

The weight is about 780kg

£1150.00.....(SOLD)







=========================================================

Startrite 18-S-10
Vertical Bandsaw

ust removed from a college, large capacity machine with a 18 inch throat,
10 blade speeds, so can be used for metal or wood, blade welder,
19" x 19" split table which tilts and is marked in degrees,
14" fence, instabrake safety DC injection emergency
braking system, the overal dimensions are  68" high x 38" deep
x 24" wide,    the weight is about £400kg

£650.00.....(SOLD)




=========================================================
Viceroy Power Hacksaw

Viceroy power hacksaw, 110mm capacity in round bar,
swivel vice for mitre cutting, sliding weight and hydraulic
damper for feed rate, has a small 3 phase motor,
takes 12" blades, with a new spare blade,
mechanical coolant pump, auto switch off,
dimensions...34" wide x 16" deep x 35" high
A nice small compact machine.

£275.00.....(No v.a.t. to add)







=========================================================

Harrison M300 Long-Bed
Centre Lathe

12" swing with 40" between centres, Newall Saphire 2 axis Digital
readout system, imperial & metric screwcutting
gearbox with powerfeeds to the carriage and crosslide, 3 morse
taper to the tailstock, imperial dials, 3 jaw and 4 jaw
chucks, 4 way toolpost, coolant system, rear splash guard,
and instruction & parts manual.

£1950.00.....(SOLD)









=========================================================

Colchester Triumph 2000
Centre Lathe
Well Tooled !!!!

t has a 15" swing with 50" between centres,  Gap-bed,  4 morse taper to
the tailstock, imperial and metric screwcutting gearbox with powerfeeds
to the carriage and crosslide, 16 spindle speeds 25 to 2000 rpm,
3 phase motor, Dixon quick change toolpost,
forward and reverse lever, Spindle Brake, 250mm 3 jaw chuck,
with 2 sets of jaws, 4 jaw chuck, fixed and travelling steadies,
coolant pump, splash guard and an instruction manual.

The overall dimensions are 95" long x  35" deep x  53" high......

The weight is about 1100kg

£1750.00.....(NOW SOLD)







=========================================================

Smart & Brown 1024 VSL
Toolroom Lathe

Choice of Two....Superb Machines

Toolroom standard machines, these Smart and Brown lathes
are the best money can buy, in very nice condition showing very little wear
and very quiet when running,  11" swing with 24" between centres,
3 morse taper to the tailstock, screwcutting gearbox with powerfeeds
to the carriage and crosslide, electric variable spindle speeds 40 to 2500 rpm,
dual imperial and metric dials, 3 phase 3 h.p. motor,
it has the very desirable 'Impero' quick change toolpost with 6 toolholders,
forward and reverse switch and also jog, 3 jaw chuck with 3 sets of jaws,
fixed and travelling steadies, driver plate and some other tooling
as seen in the photo's, coolant system rear splash guard.

the overall dimensions are 65" long x  38" deep x  55" high......

The weight is about 1100kg

You are welcome to view this machine running, ring to arrange this.

The price is £1650.00.







=========================================================

Abwood Double-Ended
Tool Grinder

Twin tilting tables with adjustable angle setting,
coolant system,

£175.00.....(SOLD)









=========================================================

Elliott 14S Shaper

14" stroke, (adjustable), swivelling clapper box,
automatic crossfeed (adjustable), 3 phase motor,

£525.00.....(SOLD)







=========================================================

Woodhouse Mitchell
70 Junior Lathe

7" centre height x 40" between centres, Gap-Bed,
8 speeds up to 437 rpm, spindle hole about 38mm, 3 morse
taper to the tailstock, screwcutting gearbox with powerfeeds
to the carriage and crosslide, imperial dials, 4 way toolpost,
3 jaw chuck, 4 jaw chuck, fixed and travelling steadies,
screwcutting dial, older machine does the job, 3 phase motor,
(easy to change to single phase) clutch handle removed,
now direct drive, with machine light and coolant pump.
An inexpensive machine.
The overall dimensions are 80" long x 50" hgh x 38" deep.

£575.00.....(SOLD)




=========================================================



<script type="text/javascript">

var _gaq = _gaq || [];
_gaq.push(['_setAccount', 'UA-29615423-1']);
_gaq.push(['_setDomainName', 'premiermachinetools.co.uk']);
_gaq.push(['_setAllowLinker', true]);
_gaq.push(['_trackPageview']);

(function() {
var ga = document.createElement('script'); ga.type = 'text/javascript'; ga.async = true;
ga.src = ('https:' == document.location.protocol ? 'https://ssl' : 'http://www') + '.google-analytics.com/ga.js';
var s = document.getElementsByTagName('script')[0]; s.parentNode.insertBefore(ga, s);
})();

</script>



===========================================================
